Parachim Vinylester

Article Number
104696

Two-component, styrene-free chemical anchor for tension-free anchoring of heavy loads by means of threaded rods. With ETA approval for uncracked concrete and hollow and solid masonry. Can be applied in dry, wet and flooded boreholes without loss of performance. Thixotropic and suitable for ceiling applications. Also with ETA approval for retrofitting reinforcing bars in reinforced concrete. With color indicator for visual control of the open time (blue turns gray). Can be applied with a standard electric, pneumatic or high-quality manual caulking gun with a high transmission ratio.

  • Two component anchoring mortar for anchoring into solid and hollow materials
  • Superior performance for structural applications: Anchoring is suitable for non-cracked concrete, reinforced or non-reinforced, from strength class C20/25 up to a maximum of class C50/60.
  • For retrofitting reinforcement bars: suitable for reinforced or non-reinforced concrete from strength class C12/15 up to a maximum of C50/60.
  • Perfect for all stress-free anchoring
  • Styrene free, can be used in confined spaces
  • Ready to use, pre-cut packaging
  • Suitable for dry, wet and flooded holes without loss of performance
  • Suitable for overhead installations (without additional accessories)
  • Fast loading time
  • With colour indicator for working time (blue turns grey)
  • Anchoring may be placed close to the edges (see table installation parameters)
  • Can be applied with a standard cartridge gun
  • Chemical resistant to many acids, bases, solvents, hydrocarbons, sea water... (Contact the technical service)
Parachim Vinylester is available to buy in increments of 12.

More Information
Type of product Vinylester
Short description

Two-component, styrene-free chemical anchor for tension-free anchoring of heavy loads by means of threaded rods.

Applications
  • Suitable for high load structural anchoring applications, ideal for fixing awnings, boilers, railings, balustrades, air conditioners...
  • Suitable for retrofitting reinforcing bars in reinforced concrete tones
  • French VOC emission class A+
  • ETA 19/ 0744 according to EAD 330499-01-0601 M8 - M24 for fixing and/or supporting to non-cracked concrete, structural elements (which contributes to the stability of the works) or heavy units.
  • ETA 19/ 0743 according to EAD 330076-00-0604 M8 - M12 for fixing and/or supporting to masonry, structural elements (which contributes to the stability of the works) or heavy units.
  • ETA 22/0326 according to EAD 330087-01-0601¯8 - ¯20 for post-installed reinforcement connections in existing structures of normal weight concrete.
A+ CE ETA
